Mirada Infrared Heated Mirror – 48″

• Product Sheet – English
• User Manual – English
• D113412 Light Kit Manual

• The front panel is constructed with 5mm TSG-H toughened safety glass.
• It operates on a power supply of 115V with a power rating of 640 Watts.
• The frequency is 50 Hz.
• It has an IP rating of IP X4 and belongs to Protection Class I.
• The heating technology used is ESHC.
• The connection cable provided is 76 inches long and white in color.
• It comes with a SCHUKO plug.
• The unit is certified by VDE.
• A 1-year warranty is included.

• The slim design is 0.86 inches thick, with a distance from the wall of 1.2 inches.
• It offers minimal wall clearance, approximately 2 inches.
• The unit features high-quality single-pane toughened safety glass with a Heat Soak Test (TSG-H).
• Rounded glass edges and corners have a radius of 0.2 inches.
• The rear panel is made of 0.6-inch galvanized metal housing, powder-coated white.
• Integrated thermal safety switches are included for added safety.
• It has highly efficient rear insulation.
• The unit comes with a built-in stainless steel heating element.

HM0480: 36” Mirror

HM0640: 48″ Mirror

HM0760:  60″ Mirror

LK0480:  36″ Light Kit

LK0640:  48″ Light Kit

LK0760:  60″ Light Kit

RT0000:  115V Radio Thermostat

MR0010:  Receiver

CK0400:  115V Connection set for LED Lightframe (includes transformer, dimmer, switch)

TF0400:  Transformer

DM0400:  Dimmer

RS0400:  Switch
